Swift springs are a great way to Improve ride quality and customize your coilovers spring rates. Most coilover brands do not recommend going more than 2-4K higher or lower than original spring rates for the best damper performance.

If you are not sure which springs your kit needs, please ask and we will be happy to help!

• 8" Length Swift Springs
• Sold as a single coilover spring
• Straight Type

PART #	SPRING RATE	USABLE STROKE	MAX STROKE	MAX LOAD
	lbs/inch	inch	inch	lbs
080-250-100	100	5.8	5.8	582
080-250-125	125	5.6	5.6	710
080-250-150	150	5.7	5.7	877
080-250-175	175	5.2	5.7	985
080-250-200	200	5.1	5.8	1,151
080-250-225	225	4.9	5.7	1,280
080-250-250	250	4.8	5.6	1,402
080-250-275	275	4.7	5.5	1,516
080-250-300	300	4.7	5.4	1,620
080-250-350	350	4.6	5.2	1,837
080-250-375	375	4.5	5.2	1,953
080-250-400	400	4.4	5.2	2,066
080-250-425	425	4.3	5.1	2,172
080-250-450	450	4.3	5.1	2,273
080-250-475	475	4.3	5.0	2,371
080-250-500	500	4.2	4.9	2,461
080-250-525	525	4.2	4.8	2,544
080-250-550	550	4.1	4.9	2,679
080-250-600	600	4.0	4.8	2,884
080-250-650	650	4.0	4.6	3,009
080-250-700	700	3.9	4.5	3,180
080-250-1000	1000	3.6	4.1	4,130
080-250-1100	1100	3.5	3.9	4,339
080-250-1200	1200	3.4	3.9	1,729
080-250-1300	1300	3.2	4.0	5,220
080-250-1400	1400	3.2	3.8	5,298
080-250-1500	1500	3.2	3.5	5,309
080-250-1600	1600	3.0	3.8	6,041
